AI Functions: Vehicle Detection
Shell Material: Plastic
Color Night Vision: no
Operating Temperature: -10°-60°
IP Rating: IP66
Scene: Indoor and Outdoor
Digital Zoom: 2X
Optical Zoom: Other
Megapixels: 6MP
TF Card: None
Power Supply: With POE
Storage: None
Installation: Ceiling
Color: WHITE
is_customized: No
Audio Output: 1CH BNC
Viewing Angle : 360°
Video Compression Format: H.264,H.265
IR Distance(m): 20M
Power Supply(V): 12 VDC ± 10%
Alarm Action: Email Photo
Power Consumption(W): < 10 W
Sensor Brand: Sony
Special Features: Vandal-proof
Sensor: CMOS
Model Number: PTZ-3601-IZ
Supported Operating Systems: Windows 7
Lens (mm): 2.8-8mm
Connectivity: IP/Network Wired
High Definition: 6.0 Megapixels
Style: Dome Camera
Brand Name: VIKYLIN
Origin: Mainland China
Certification: CE
Smart home platform: Other
Type: 6MP 3X Human & Vehicle Detection POE PTZ Dome
Wall Bracket: Ceiling
Technology: Infrared
Network Interface: 1-RJ45, 100Mbps, POE optional
CMOS: 1/2.8 CMOS
Max.Resolution: 3072×2048
Day/Night: Auto/Scheduled
Main Profile: H.265 CCTV Camera
Zoom: 3x optical zoom
Aperture Range: F1.2
Number of Preset: 255
Camera: Hikvision Compatible 4MP 4X Zoom IR PTZ Network IP Camera
Focal length: 2.8-8mm motorized AF lens
Manual Control Speed: Pan: 0.5° ~80° /s; Tilt: 0.5° ~60° /s
Pan/Tilt Range: Pan: 0° ~ 350°; Tilt: 0° ~ 90°

6MP POE PTZ Security Camera Dome 3X Optical Zoom 2.8-8MM Human & Vehicle Detection Built-in Mic Video Surveillance Cameras IP66

Before Order:

1.What is”HIK Protocl”?
HIK products all have HIK Protocl and it support HIK camera plug and play, make it easy to be install with HIK NVR.
2.What is”HIK compatible”?
It mean this camera support plug & play with HIK NVR(Also HIK software).
You don’t need to manual setting camera IP and password etc…
Just plug in and camera will work!
3. When I installed the camera, How Can I find this camera?
download software:AJDevTools（Recommend）
http://www.anjvision.com:8021/client/AjDevTools_V5.2.1_20210108.exe
Or SADPhttps://www.HIK.com/content/dam/HIK/en/support/download/tools/sadp/for-windows/v3-0-2-4/firmware/SADP-Tool-for-Window.zip
use this software search the camera.
username: admin
password: 123456

Key Feature :

PTZ-3601-IZ
6MP 3X Human & Vehicle Detection POE PTZ Dome
> 1/2.8″ Sony low-light CMOS sensor
> 6MP 25fps resolution 3072×2048
> low illumination 0.01Lux
> HD 2.8-8mm motorized AF lens , Network PTZ control , 3X optical zoom
> Day/Night, AWB/MWB, BLC, HLC, 2D/3D-DNR, Shutter, IR-CUT
> D-WDR, Mirror, flip, Defogging
> Multiply Style OSD Overlay,Motion Detection, Privacy Mask
> RTSP and O-n-v-i-f 17.06 compatible with many third-party NVR
> Smart 265/264 dual-stream media server
> Easy-to-use P2P Cloud service
> Support user authentication, video data encryption
> Support Alarm Snapshot to Email and FTP
> Multiply WEB browser IE,Firefox 32bit ESR, PC Client, Mobile APP remote access
> Lightning protection 4000V
> Strong water-proof housing IP66
> 3 pcs Array IR Leds, IR distance 20-30 meters

Support Night Vision

The smart IR-Cut filter switches automatically between day and night to reduce color cast in day time and enhance image brightness at night making sure you can get vivid surveillance footage from dawn to dark)

3.0X Optical Zoom

The camera supports 3X Optical Zoom, Press and hold the screen with both hands to Zoom in/Out

Pan/Tilt Function

The lens of this PTZ camera can be rotated, you can see a wider area by remotely controlling the camera on your mobile phone, so that the monitoring doesn’t leave blind spots

Built-in Mic (Support 1-way audio recording)

Motion Detection and Alarm

Whenever a danger is detected, this surveillance camera will trigger alerts by immediately sending alert e-mails and pushing notifications to your device.You can create specific motion detecting zones to monitor certain areas as you want. You can adjust motion detection sensitivity to reduce false alerts
